Sanwa/Airtronics PGS-CX II Hi-Torque Programmable Servo (High Voltage)

The Sanwa/Airtronics PGS-CX II is a high-voltage, hi-torque programmable servo with a coreless motor, metal gears and an AL heat sink. It supports SSL, SSR and SHR modes, along with two-cell LiPo battery operation.

Features

• SSL compatible with CODE10: M12S (RS), Exzes ZZ and MT-44
• Not compatible with CODE5: M12, Exzes Z, MT-4S, MT-4 and MT-S
• MULTI SETTING GEAR compatible
• Not compatible with PGS SETTING GEAR
• Telemetry transmission for temperature, current, voltage and servo position
• Wireless setting adjustment from the radio is available with SSL
• Initial setting on Multi Setting Gear is necessary

Programmable Settings

• SSL-CH: SSL Channel Setting
• STRETC: Stretcher Adjustment
• BOOST: BOOST Adjustment
• D-Band: Dead Band Adjustment
• MV-MID: Middle Torque Adjustment
• MV-END: Later Torque Adjustment
• BREAK: Break Adjustment
• MV-HOLD: Power Adjustment at whole area
• MV-FRQ: Feeling Adjustment at whole area; Multi Setting Gear is required
• MAX-PW: MAX Duty Adjustment; Multi Setting Gear is required

Specifications

• Speed at 7.4V: 0.11 sec / 60°
• Speed at 6.0V: 0.13 sec / 60°
• Torque at 7.4V: 368.01 oz-in (26.5 kg-cm)
• Torque at 6.0V: 323.57 oz-in (23.3 kg-cm)
• Dimensions: 40.5 X 20.5 X 37.2 mm
• Weight: 59 g
