Reefs RC 8.4V Slim EZ Plug-N-Play Dual Servo BEC

Reefs RC 8.4V Slim EZ Plug-N-Play Dual Servo BEC

$64.99 USD
$64.99 USD
Sale Sold out

The Reefs RC 8.4V Slim EZ Plug-N-Play Dual Servo BEC supplies power to two high-voltage servos from a single BEC. It accepts 2-6S LiPo batteries and provides a regulated 8.4V output through a plug-and-play design.

Features

  • Regulated 8.4V output
  • Compatible with 2-6S LiPo batteries
  • Plug-and-play installation
  • Supports two servos
  • Designed to avoid complex wiring modifications

Two servos can connect to the BEC harness using compatible Reefs RC XT60 and XT90 Dual JST adapters, SEHREEFS121 and SEHREEFS122, sold separately. Plug the unit into the preferred receiver channels for power delivery to high-voltage servos.

Specifications

  • Input: 2-6S LiPo (7.4-22.2V)
  • Output: 8.4V
  • Output Current: 10A (Maximum - 15A)
  • Dimensions (LxWxH): 1.38x0.71x0.44in (35x18x11.2mm)

Tech Note: Input voltage must be more than 10V to provide the 8.4V output voltage. When using a 2S LiPo, the output voltage will be 7V. This version is not waterproof. For a water-resistant version, see the Reefs RC Standard 8.4V EZ Plug-N-Play Dual Servo BEC (SEHREEFS262).

Includes

  • (1) Reefs RC 8.4V Slim EZ Plug-N-Play Dual Servo BEC
