Reefs RC 8.4V Slim EZ Plug-N-Play BEC

The Reefs RC 8.4V Slim EZ Plug-N-Play BEC provides regulated power for high-voltage RC servos with a straightforward receiver connection. Its slim design supports space-conscious installations without complex wiring or connector modifications.

For direct servo connection, it is compatible with Reefs RC XT60 and XT90 Dual JST adapters, SEHREEFS121 and SEHREEFS122, sold separately.

Features

• Regulated 8.4V output
• Compatible with 2-6S LiPo batteries
• Plug-and-play installation
• Eliminates complex wiring modifications
• Supplies consistent power to high-voltage servos
• Slim, space-saving design

Specifications

• Input: 2-6S LiPo (7.4-22.2V)
• Output: 8.4V
• Output Current: 12A (Maximum - 15A)
• Dimensions (LxWxH): -

Tech Notes: Input voltage must be more than 10V to provide the 8.4V output voltage. When using a 2S LiPo, the output voltage will be 7V. This version is not waterproof. For a water-resistant version, see the Reefs RC Standard 8.4V EZ Plug-N-Play BEC (SEHREEFS206).

Includes

• (1) Reefs RC 8.4V Slim EZ Plug-N-Play BEC
