Redcat Vertex-6 Crawler 1/6 RTR 4WD Electric Brushless Rock Crawler (Grey)

The Redcat Vertex-6 is a 1:6 scale RTR 4WD electric rock crawler with brushless power, a low center of gravity chassis and advanced suspension geometry. It includes a 2.4GHz 4-channel radio system and is designed for controlled performance across challenging terrain.

Brushless Power and Electronics

A Hobbywing Fusion RTR 2-in-1 FOC system combines a 4269 1800KV brushless motor with a programmable ESC. The system supports 3-4S LiPo power and includes an 8.4V BEC. Steering is handled by a large-scale HX-LS digital servo with metal gears and 972oz/in of torque.

Suspension and Steering

• Oil-filled emulsion shocks with X-ring seals
• Double CV joints for smooth articulation at extreme steering angles
• Adjustable Ackerman geometry with included tuning blocks
• Transmitter selectable 0% and 30%
• 7" soft compound aggressive tread crawler tires

Durability Features

• Steel internal axle tubes
• Heavy duty metal driveshafts
• Reinforced solid axles with steel internal tube inserts
• Hypoid-style ring and pinion gears
• Forward-mounted motor and low center of gravity chassis
• High-clearance rear links
• Tilt body mounting system

Specifications

• Scale: 1:6
• Drive: 4WD
• Power Source: 3-4S LiPo
• Length: 31.4in (800mm)
• Wheelbase: 19.5in (495.3mm)
• Width: 15.7in (400mm)
• Height: 9.9in (253mm)
• Weight: *12.5lb (5669.9g)
• Motor: Brushless
• ESC: Brushless
• Connector: XT60
• Servo: HX-LS 70kg
• Hex: 17mm
• Assembly Level: RTR

Includes

• (1) Redcat Vertex-6 LCG Crawler
• (1) 2.4GHz 4-Channel Radio System

Needed to Complete

• (4) AA Batteries for Transmitter
• (1) 3-4s Lipo Battery w/XT60 Connector
• (1) Compatible Battery Charger
