Hitec D485HW Karbonite Standard Servo (High Voltage)

The Hitec D485HW Karbonite Standard Servo is a high-voltage, sport-class digital servo featuring D-series high-resolution 32-bit technology and wide voltage operation. It replaces the standard-size HS-5485HB and HS-5495BH servos.

Specifications

• Operating voltage: 4.8V ~ 7.4V DC
• Speed: 0.20 ~ 0.15 second @ 60°
• Maximum torque: 72 ~ 104 oz./in.; 4.8 ~ 7.4 kg./cm.
• Current draw at idle: 30 mA
• No-load operating current draw: 320mA
• Stall current draw: 1,500mA
• Dimensions: 1.57 x 0.78 x 1.49 inches; 39.8 X 19.8 X 38.0 metric
• Weight: 1.59 ounces; 45.0 grams
• Circuit type: 32 bit programmable digital
• Motor type: 3 Pole Cored Carbon Brush
• Gear material: MK 1st Gear & 3 Karbonite Resin Gears
• Bearing type: Top Ball Bearing
• Output shaft: Type 25 / Ø6mm
• Case material: Plastic

Warranty

Each Hitec servo is backed by a limited two-year warranty from the date of purchase. Hitec RCD USA, INC. shall repair or replace defective equipment covered by this warranty.
