Xpert MM-3302T-HV All Aluminum Case Mini Tail Servo (High Voltage)

The Xpert MM-3302T-HV is a high-voltage mini tail servo for helicopter applications, featuring a brushless motor, full aluminum case, strong metal gears, and 4096 resolution.

Features

• Brushless motor design
• Full aluminum case for thermal dissipation and durability
• 4096 resolution with SIC (Single Integrated Circuit)
• Strong metal gear
• Sophisticated error correction
• High-speed, high-precision 12-bit AD converter and CPU calculation
• Fail safe, over current protection, and over temperature protection
• Start sonorant 760us narrow band

Specifications

• Type: Mini
• Product Name: MM-3302T-HV(M1T)
• Part Name: MM-3302T-HV(M1T)
• Power Supply: 6.0V~8.4V
• Speed: @6.0V: .068 sec/60°; @7.4V: .055 sec/60°; @8.4V: .049 sec/60°
• Torque: @6.0V: 118.95 oz-in; @7.4V: 146.71 oz-in; @8.4V: 166.56 oz-in
• Torque: @6.0V: 8.57 kg-cm; @7.4V: 10.57 kg-cm; @8.4V: 12 kg-cm
• Dimensions: 33.6x15x29.5 mm
• Weight: 40.5 g
• Frequency: 200/333 Hz
• Range: 50~400 Hz
• Center Position: 760 μs
• Applications: Helicopter Tail
• Upper and Bottom Case: XC-04T
• Hardware Parts: Xpare-03
• Gear Set: XPTXGS72000
