Xnova XTS 4530-525KV 4+5YY Brushless Motor w/6mm Shaft (Shaft A)

The Xnova XTS 4530-525KV 4+5YY Brushless Motor features a 6mm Type A shaft measuring 38mm in length. It is developed for 700-800mm helicopters, optimized for 12S applications, and recommended for extreme 3D flying.

Features

• 100% hand-wound construction
• High-quality Neo Magnets, heat resistant up to 150 degree C
• Specialized wires, heat resistance up to 300 degree C
• Precise balanced design
• High-performance stator metal sheet
• High-quality NMB bearings
• Efficiency up to 94%
• CNC-machined parts
• 1.5mm thick wire

Specifications

• Slots & Poles: 12n10p
• Winding: 4+5 YY with 1.5mm thick wire
• RPM/V: 525
• Weight (without connector): 535g
• Body Length (no shaft): 60.5mm
• Diameter: 55.7mm
• Shaft Length: 38mm
• Shaft Dia.: 6mm
• Mounting Holes CTC Distance: 30mm
• Mounting Screw: 4x07
