Xnova XTS 4525-560KV Brushless Motor (Shaft A)

The Xnova XTS 4525-560KV YY Brushless Motor features a 6mm Type A shaft measuring 36mm in length. Designed for 630-700mm helicopters, this motor is optimized for 12S applications and extreme 3D flying.

Features

• 100% hand-wound
• Complete quality control testing before shipping
• High quality Neo Magnets, heat resistant up to 150 degree C
• Specialized wires, heat resistance up to 300 degree C
• Precise balanced
• High performance stator metal sheet
• High quality NMB bearings
• Cooler running
• CNC-machined parts
• Improved torque and power output
• 1.5mm thick wire

Specifications

• Slots & Poles: 12n10p
• Winding: YY with thick wire
• RPM/V: 560
• Weight without connector: 480g
• Body Length, no shaft: 55.5mm
• Diameter: 55.7mm
• Shaft Length: 36mm
• Shaft Diameter: 6mm
• Mounting Holes CTC Distance: 30mm
• Mounting Screw: 4x07
• Max Continuous Power: 5000 Watts
• Peak Continuous Power: 10000 Watts
• Max Continuous Current: 100A
