Xnova XTS 2618-1360KV Brushless Motor (Shaft A)

The Xnova XTS 2618-1360KV HP Brushless Motor with Shaft A is designed for helicopters using 325-380mm main blades on 6s LiPo. It is developed for 3D flying and long flight times, with a hand-wound single-strand wire design and quality-control testing before shipping.

Features

• Designed for 3D flying and long flight times
• Developed for 325-380mm helicopters on 6s LiPo
• High quality Neo Magnets, heat resistant up to 150 degree C
• Specialized wires, heat resistance up to 250 degree C
• Precise balanced high performance stator metal sheet
• High quality NMB bearings
• Cooler running
• CNC-machined parts
• 100% hand-wound

Specifications

• Slots & Poles: 12n10p
• Winding T: 13D
• rpm/V: 1360
• Volt (V): 10 / 22.2
• Io(A): 1.6 / 3.0
• Rm (mohm): 25
• Weight (without connector): 108g
• Body Length (no shaft): 38.1mm
• Diameter: 33mm
• Shaft Length: 17.4mm
• Shaft Dia.: 3.5mm
• Mounting Holes CTC Distance: 19*2 & 16*2
• Mounting Screw: M3x0.5
• Max Eff. Curr.: 25.30 / 51.61
• Max Eff.: 87.35 / 88.38
• Kt (Nm/A): 0.007
• Km (Nm/sqrt(w)): 0.0444
• Max Continuous Power(Watts): 720
• Peak Continuous Power(Watts) (2 sec): 960
• Max Continuous Current(Amps): 36
