Xnova 4025-560KV 3Y V3 Brushless Motor w/6mm Shaft (Shaft B)

The Xnova 4025-560KV 3Y V3 Brushless Motor features a 6mm Type B shaft measuring 28mm long. It is developed for the Goblin 570 and is recommended for sport flying on 8-10S or extreme 3D on 10-12S.

Features

• Type B shaft, 28mm long and 6mm diameter
• High quality Neo Magnets, heat resistant up to 150 degree C
• Specialized wires, heat resistance up to 250 degree C
• Precision balanced
• High performance stator metal sheet
• Optimized ventilation
• High quality NMB bearings
• Marked leading high efficiency up to 92%
• Superb quality and machining of CNC parts

Specifications

• Slots & Poles: 24n8p
• Winding T: 3Y
• rpm/V: 560
• Volt (V): 10 | 20 | 30
• Io(A): 0.9 | 1.2 | 1.6
• Rm (mohm): 19 | 19 | 19
• Weight (without connector): 384g
• Body Length (no shaft): 55.75mm
• Diameter: 49.5mm
• Shaft Length: 28mm
• Shaft Diameter: 6mm
• Max Eff. Curr.: 21.76 | 35.54 | 50.26
• Max Eff.: 91.73 | 93.25 | 93.63
• Kt (Nm/A): 0.0171
• Km (Nm/sqrt(w)): 0.1237
• Max Continuous Power (Watts): 3000
• Peak Continuous Power (Watts) (5 sec): 4000
• Max cont. current (A): 68
