Vanquish Products VS4-10 Currie D44 Rear Axle (Clear)

The Vanquish Products VS4-10 Currie D44 Rear Axle is an officially licensed Currie Enterprises RockJock 44 style axle housing in clear finish. It features patent-pending one-piece bearing retainers, rear bearing retainer caps for a scale appearance, and double-shear shock mounts.

This is not a complete axle assembly. The D44 uses Vanquish Products AR44 gear sets and spools and requires additional components and bearings to complete.

Features

• Fully licensed by Currie Enterprises
• One-piece bearing retainers
• Rear bearing retainer caps eliminate the need for lockouts
• Double-shear shock mounts
• Uses Vanquish Products AR44 gear sets and spools

Recommended For Use With

• Vanquish VS4-10 Chassis Kit (VPS10130)
• Incision 90mm shocks (IRC00210)
• Vanquish Rod Ends and Pivot Balls (.280" width pivot balls)
• Incision Link Kit (IRC00070 or IRC00071)
• Vanquish Products 6-Hole AR44 Gear Set (VPS08330)
• Vanquish Products 6-hole AR44 Spool (VPS08070)

Not for use with Vanquish Products Brass Pivot Balls (.300" width). Due to the nature of the AR44 gear design, proper shimming of the pinion gear may be required for optimal results.

Includes

• Currie Rear Housing
• Two Bearing Retainers
• Currie Diff Cover
• Two Axle End Caps
• Required hardware
• Instructions

Required To Complete

• Hexes, hex pins, bearings, kingpin, knuckles, ring and pinion gear, and locker
• Two 7x14x3.5 Bearings
• One 5x14x5 Bearing
• Three 5x11x4 Bearings
