Tekin RX8 GEN3/Redline T8 GEN3 1/8 Truggy Brushless ESC/Motor Combo (2250kV)

The Tekin RX8 GEN3 and Redline T8 GEN3 combo pairs a 1/8 scale brushless ESC with a 2250kV truggy motor. The RX8 GEN3 supports sensored and sensorless motor operation through Tekin D2 Dual Drive Mode Technology, while the T8 GEN3 features a 4-pole neodymium sintered magnet, rebuildable design and low-resistance solder tabs.

RX8 GEN3 ESC Features

• Controls forward, brake and reverse
• Compatible with brushless and brushed motors
• Programmable 6.0v / 7.4v BEC at 8amps
• 2S-6S LiPo / 4-16S NiMH-NiCD input voltage
• 300amps per phase maximum current and 1000amps per phase burst current
• Seven onboard timing profiles
• Adjustable torque control, throttle frequency and brake frequency
• HotWire 3.0 Bluetooth connectivity, EZ Access HotWire programming port and data logging capability
• On-board temperature indicator, self-test diagnostics and factory reset
• HDAC high-density copper PCBs and DGF2 digital glitch filtering
• ROAR Approved

T8 GEN3 Motor Features

• 2250kV, rated for 4S
• Sensored and sensorless operation
• CNC machined 6061 T6 billet aluminum ribbed heatsink can
• Matte anodized finish for corrosion resistance
• Low-resistance HD solder tabs
• Rebuildable design with solderless sensor PCB replacement
• ABEC5 precision high-speed oversized bearings
• Dual-plug sensor wire harness

Specifications

• RX8 GEN3 dimensions: 1.5 x 2.2 x 1.4" / 38 x 55.8 x 35.5mm
• RX8 GEN3 weight: 2.7oz / 76.5g
• T8 GEN3 weight: 368g / 13oz
• T8 GEN3 shaft dimensions: 5mm (.125") x 19mm
• T8 GEN3 motor diameter: 40mm / 1.57" (42mm / 1.65" including fin)
• T8 GEN3 motor length: 77mm / 3.03"
• T8 GEN3 bearing dimensions: Front: 5 x 16 x 5mm / Rear: 5 x 11 x 5mm
• Rotor size: 18.5mm
• Rebuildable: Yes
