Team Brood Riot 41mm Sensorless Outrunner Brushless Crawler Motor (1000Kv)

The Team Brood Riot 41mm Sensorless Outrunner Brushless Crawler Motor is designed for scale, trail, comp, U4-style and rock racer applications. Its compact, lightweight design combines 0.2mm Kawasaki Steel laminations, N42 Neodymium magnets and a 14-pole/12-slot configuration.

Features

• Sensorless brushless outrunner design
• 0.2mm Kawasaki Steel laminations
• N42 Neodymium magnets
• 14 poles/12 slots for torque, power and smoother startup
• Water-resistant design; post-run maintenance is required after exposure to water
• CNC machined 6061-T6 Aluminium Housing
• Standard 540 M3 mounting pattern
• Standard 1/8" shaft with D Cut
• Factory-wired with 4.5" 16AWG silicone wire
• 1 Year Limited Warranty

Specifications

• Kv: 1000Kv
• Type: 14 pole/12 slot Brushless Outrunner
• Magnets: N42 Neodymium Magnets
• Length: 41mm
• Diameter: 35mm
• Stator: 28x20mm
• Laminations: 0.2mm Kawasaki Steel
• Weight: 135 grams
• Input Voltage: 2s-4s Lipo
• Mounting Pattern: M3 25mm
• Shaft Diameter: 1/8" with flat (3.175mm)
• Wire: 4.5" 16AWG Silicone wire

The warranty covers manufacturing defects and does not cover water damage, rust, heat damage from overgearing, modifications, improper installation, misuse or abuse.
