Team Brood Ravage Machine Wound 540 5 Segment Dual Magnet Brushed Motor (16T)

The Team Brood Ravage 16T is a machine-wound 540 brushed motor with a five-segment armature, dual C6 magnets, adjustable timing and rebuildable construction. Each motor is assembled with precision-focused processes, fully broken-in and tested on calibrated equipment before leaving the factory.

Features

• Dual Magnet Can with C6 magnets
• Adjustable timing for fine-tuning the powerband
• Rebuildable design
• Dual precision ball bearings
• Aluminum heatsinks for additional cooling
• Standup brushes with optimal tension springs
• Machine-wound copper armature
• 30 Day Limited warranty through manufacturer

Build Features

• Cleaned and lubed bearings
• Precision-spaced armature
• Precision-measured springs
• Aligned brush hoods
• Each component tested on precision calibrated equipment
• Fully broken-in and ready to install and run

Specifications

• Poles: 2
• Magnets: Dual C6
• Brush Style: Standup
• Voltage Input: 3.7v-14.8v
• Break-In: 300 seconds at 3 volts, 30 seconds at 3.5 volts
• Armature Construction: Machine wound
• Lamination Size: .014"
• Stack Design: Skew
• Slots: 5
• Wire Type: Copper Round
• Balance Type: Drill
• Turns: 16T
• Weight: 6 ounces
• Length: 54mm (2.125")
• Diameter: 35.85mm (1.41")
• Shaft Size: 3.175mm (1/8th)
• Mounting Pattern: Standard 540 M3x25mm
