Team Brood Monster Truck Machine Wound 540 Clod Buster Motor (23T)

The Team Brood Monster Truck Machine Wound 540 Clod Buster Motor is a 23-turn, 3-segment brushed motor developed for spec solid axle monster truck racing. It features 0 degrees timing and a machine-wound armature.

Motor Specifications

• Poles: 2
• Magnets: Dual CR6
• Brush style: Standup
• Voltage input: 3.7v-14.8v
• Break-in: 300 seconds at 3 volts, 30 seconds at 3.5 volts
• Turn count: 23 turns
• Armature construction: Machine Wound
• Lamination size: .2mm
• Stack design: Skew
• Slots: 3
• Web: 4mm
• Commutator size: 7.5mm (.300")
• Wire type: Copper Round
• Balance type: Drill

Dimensions

• Weight: 6 ounces
• Length: 54mm (2.125")
• Diameter: 35.85mm (1.41")
• Shaft size: 3.175mm (1/8th)
• Mounting pattern: Standard 540 M3x25mm
