Team Brood Demolition 550 5-Slot Skewed Machine Wound Brushed Motor (16T)

The Team Brood Demolition 550 5-Slot Skewed Machine Wound Brushed Motor is built for budget-conscious crawlers seeking a larger can 550 motor with a carefully prepared, rebuildable design. Each motor is hand shimmed, precision aligned, lightly broken in, and dyno tested before installation.

Features

• Dual C6 magnets for torque and brake strength
• Adjustable timing for fine-tuning the powerband
• Rebuildable design
• Dual precision ball bearings
• Aluminum heatsinks for additional cooling
• Standup brushes with optimal tension springs
• Machine wound armature
• 30 Day Limited warranty through the manufacturer

Build Features

• Cleaned and lubed bearings
• Precision-spaced armature
• Precision-measured springs
• Aligned brush hoods
• Components tested on precision calibrated equipment
• Fully broken in and ready to install and run

Specifications

• Motor: 2 poles, dual C6 magnets
• Brush style: Standup
• Voltage input: 3.7v-14.8v
• Break-in: 300 seconds at 3 volts, 30 seconds at 3.5 volts
• Armature construction: Machine wound
• Lamination size: .014"
• Stack design: Skew
• Slots: 5
• Wire type: Copper round
• Balance type: Epoxy
• Turns: 16T
• Weight: 8 ounces
• Length: 63mm (2.48")
• Diameter: 35.85mm (1.41")
• Shaft size: 3.175mm (1/8th)
• Mounting pattern: Standard 540 M3x25mm
