Team Brood B-Mag TLR 22 Magnesium Slipper Eliminator (Kimbrough Spur Gears)

The Team Brood B-Mag Magnesium Slipper Eliminator is a lightweight TLR 22 option designed for more instantaneous power delivery and reduced transmission rotating mass. Precision machined from AZ61 Magnesium, it features an MAO coating for a hard, durable finish and weighs 1.5 Grams.

Features

• Designed for TLR 22 Buggy series applications
• For use with Kimbrough style spur gears
• MAO-coated AZ61 Magnesium construction
• Lightweight slipper eliminator design
• Weight: 1.5 Grams

Installation Notes

Secure the Slipper Eliminator to the Kimbrough style spur gear using the included 3x5mm Button Head Screws and a small amount of thread lock. Slide the assembly onto the Top Shaft with the TLR red washer, then use the included non-serrated flanged M4 Lock Nut to secure it. Do not over-tighten the nut or screws; firmly snug is sufficient.

Only works with TLR 22 Buggy series Top Shafts. 4.0 Shafts require a Non-Serrated Flanged M3 Lock Nut. Losi 22s Drag cars must be converted to a TLR 22 5.0 Buggy Top Shaft to use the Eliminator.

Includes

• (1) Magnesium Slipper Eliminator
• (3) Nickel Plated 12.9 M3x5mm Button Head Screws
• (1) Non-Serrated Flanged M4 Aluminum Lock Nut
