Tamiya TT-02R 4WD Touring Car Chassis Kit

The Tamiya TT-02R 4WD Touring Car Chassis Kit refines the versatile TT-02 platform with racing-spec components, fully independent double-wishbone suspension and CVA oil-filled dampers. This 1/10 assembly kit uses a gear-driven 4WD system and includes full ball bearings.

Features

• Aluminum uprights with 3-degree toe-in
• Aluminum motor mount
• Adjustable gear ratio
• ABS plastic TT-02R chassis
• Fully independent double-wishbone suspension
• CVA oil-filled shock dampers
• On-road use

Included Hop-Up Option Parts

• TAM53159 4mm Aluminum Flange Lock Nut (Blue)
• TAM54247 3x18mm Aluminum Turnbuckle Shaft (Blue) x2
• TAM54501 TT-02 Aluminum Propeller Shaft
• TAM53642 5mm Aluminum Ball Connector (Blue)
• TAM54500 TT-02 High-Speed Gear Set (68T)
• TAM54502 TT-02 Aluminum Propeller Joint

Specifications

• Scale: 1/10
• Drive: 4WD
• Construction: Assembly kit
• Differential: Gear
• Wheelbase: 257mm

Needed to Complete

• 2-channel radio and receiver
• Steering servo
• 1/10 ESC
• 540 sized motor
• 257mm wheelbase body
• Polycarbonate paint
• 7.2-7.4V battery pack
• Compatible charger
• Tires
• Tools
