Savox SB-2273SGP Hyrbid "High Torque" Brushless Digital Steel Gear Servo

The Savox SB-2273SGP Hyrbid "High Torque" Brushless Digital Steel Gear Servo delivers high-torque control for 1/8 buggies, large-scale aircraft, and other demanding applications. Its brushless motor, steel gear train, hybrid case with an aluminum middle section, and 12-bit (4096) digital control are designed for smooth, consistent operation.

Features

• High-voltage capable with an input voltage of 6.0-8.4V
• Brushless motor designed for smooth, efficient operation
• Steel gear train
• Hybrid case with aluminum middle section for heat dissipation
• Dynamic torque of 388.8oz-in (28kg-cm) at 7.4V
• 12-bit (4096) resolution digital control
• Soft Start function included as part of the Plus series
• Sanwa SSR compatibility
• 25T output shaft
• Suitable for 1/8 buggies and large-scale aircraft

Specifications

• Application: 1/8 & Aircraft
• Input Voltage: 6.0-8.4V
• Operating Speed @ 6.0V: 0.12 sec/60°
• Operating Speed @ 7.4V: 0.095 sec/60°
• Operating Speed @ 8.4V: -
• Dynamic Torque @ 6.0V: 319.4oz-in (23kg-cm)
• Dynamic Torque @ 7.4V: 388.8oz-in (28kg-cm)
• Dynamic Torque @ 8.4V: -
• Gear Material: Steel
• Motor Type: Brushless
• Output Shaft: 25T
• Dimensions: 1.59x0.8x1.52in (40.3x20.2x38.7mm)
• Weight: 2.43oz (69g)

Includes

• (1) SB-2273SGP Hyrbid "High Torque" Brushless Digital Steel Gear Servo
• Servo Horns & Accessories
