REDS VX4 540 "Pro Stock" Sensored Brushless Motor (17.5T) (EFRA)

The REDS VX4 540 "Pro Stock" Sensored Brushless Motor combines an optimized stator, low-resistance copper wiring, and a precision-balanced neodymium high-temperature rotor for 1/10 applications. Its CNC-machined 2-piece can supports cooling, while adjustable timing and solder-tab connections provide setup flexibility.

Features

• Optimized stator design for improved efficiency
• Low-resistance copper wiring for maximum power
• CNC-machined 2-piece can for enhanced cooling
• Precision-balanced neodymium high-temperature rotor
• Pro Stock version with high-torque rotors for maximum acceleration
• Titanium screws to reduce iron losses
• Optional ceramic bearings for increased durability
• Factory-selected version for optimal setup
• Sensored brushless technology for smooth power delivery
• Proven reliability through extensive track testing

Specifications

• Suggested Application: 1/10
• Size: 540
• Type: Brushless Sensored
• Voltage: 7.4V (2S)
• Adjustable Timing: Yes
• Watts: -
• Connector: Solder Tab
• Dimensions: 2.02x1.41in (51.4x35.8mm)
• Shaft Diameter: 1/8in (3.17mm)
• Weight: -

Includes

• (1) VX4 540 "Pro Stock" Sensored Brushless Motor (17.5T) (EFRA)
• (1) Sensor Cable
