RC4WD Yota 2/K44 Axle Leaf Under Mounts (4)

Lower your truck by 10-12mm with the RC4WD Yota 2/K44 Axle Leaf Under Mounts. This set includes four CNC machined billet aluminum mounts with a black anodized finish.

Product Details

• Part Number: RC4ZS2135
• Quantity: 4
• Material: CNC machined billet aluminum
• Finish: Black anodized
• Total Weight: 0.56oz / 16.0g

Installation Notes

• For K44 axles, use the thicker brackets on the front and rear axle.
• For Yota II axles, use the thinner bracket on the front and thicker bracket on the rear.
• Will not fit Yota I axles.
• Modification to the shocks and shock hoops may be required.
• Installation may cause interference with steering, the driveline, or the axle pumpkin, and may limit suspension travel.
• These mounts work with either Front Shock Hoops for Gelande 2 Chassis (RC4ZS0798) or Shock Hoops for Trail Finder 2 Chassis (RC4ZS0597). A taller shock hoop should use a 60-70mm shock.
• RC4WD recommends RC4WD Bilstein SZ Series 50mm Scale Shock Absorbers (RC4ZD0081) in front and rear.
• These mounts install best with RC4WD TCI Heavy Duty R4 Single Speed Scale Transmission (RC4ZU0031) or RC4WD TCI Heavy Duty R4 Single Speed Scale Transmission w/ O/U Drive Transfer Case (RC4ZU0040).
• Driveshaft rubbing may occur with R3 Scale 2 Speed Transmission (RC4ZU0025) and R3 Scale Single Speed Transmission (RC4ZU0028).
