Holmes Hobbies Puller Pro R 540-L V2 Waterproof Sensored Race Motor (6000kV)

The Holmes Hobbies Puller Pro R 540-L V2 is a waterproof sensored race motor developed for 1/10th scale U4, rock racing, endurance, drag racing, and sled pulling. This 6000kV motor uses higher quality materials for reduced heat, increased torque, and less brake fade while maintaining low-speed control and throttle feel.

Features

• Four-pole rotor: 18mm diameter x 26mm length
• Twelve-slot stator
• 180C resin-impregnated copper windings
• 200C-rated high-strength neodymium magnets
• Oversized bearings
• Sensored waterproof sensor board
• Sensor wire included

Specifications

• Type: "550" size motor
• Mount pattern: 25mm
• Mounting hardware: M3 screws
• Shaft diameter: 5mm
• Can size: 36mm diameter x 60.5mm length
• Weight: 236.5g
• Maximum RPM: 60,000 rpm

Setup Notes

• Recommended battery: 2S LiPo, 5000mAh 35C or greater
• Recommended ESC: 1/10th or 1/8th scale suitable for 4x4 vehicles
• If the motor gets wet, clean, dry, and relube the bearings to help avoid damage.
• Do not extend screws into the motor plate more than 3.5mm or damage to the windings may occur.
• Includes a 1-year warranty from the date of purchase. Warranty does not include damage from overheating, rusting, or improper installation.
