Futaba S-U306 Digital Standard Servo

The Futaba S-U306 Digital Standard Servo is designed for car and airplane applications, combining all-metal gears with a durable composite case. It delivers 123.6oz-in (8.9kg-cm) of torque at 6.0V and supports a -60 to +60 degree output angle.

Features

• Standard digital servo
• All-metal gears
• High quality composite case
• For cars and airplanes
• -60 to +60 degree output angle

Specifications

• Speed: @4.8V: 0.23sec/60°; @6.0V: 0.18sec/60°
• Torque: @4.8V: 98.6oz-in (7.1kg-cm); @6.0V: 123.6oz-in (8.9kg-cm)
• Dimensions: 1.57x0.79x1.50" (40x20x38.1mm)
• Weight: 46.5 g
• Operating Voltage: 4.8-6.0V
• Operating Spline: 25T
• Application: Cars/Airplanes

Includes

• (1) S-U306 Digital Standard Servo
• Composite Servo arms with mounting hardware
