Castle Creations Phoenix Edge Lite 75 25V 75-Amp ESC w/5-Amp BEC

The Castle Creations Phoenix Edge Lite 75 is a brushless ESC for helicopters and fixed-wing aircraft. It supports 2S to 8S LiPo input, delivers 75 amps at full throttle with appropriate cooling, and features a user-selectable 5 to 8.4 volt BEC with 5 amp peak output.

Features

• Fully programmable Castle feature set using the Castle Link USB adapter and freely downloadable Castle Link Windows software
• Data logging and USB programming capability
• User-programmable auxiliary wire for functions including helicopter governor gain input, audible beacon operation, RPM output, ESC arming lock, or receiver arming lock
• Castle Field Link Programming Card compatible with select functions; sold separately
• Designed without a heat sink for applications with extreme airflow or average current requirements well below peak current requirements

Specifications

• Application: Helis & Fixed wing
• Input voltage: MIN: 2S LiPo; MAX: 8S LiPo
• Max continuous amperage at full throttle: 75 amps*
• BEC voltage: User selectable from 5 to 8.4 volt output
• BEC output amperage: 5 amp peak**
• Width: 1.2" (30.5mm)
• Length: 2.6" (66mm)
• Height: 0.8" (21.4mm)
• Weight w/wires: 2.9 oz (81g)
• Weight w/o wires: 1.4 oz (41g)
• Connectors: Battery and motor connectors sold separately

Installation Notes

• A soldering iron and solder are needed to attach bullets to motor wires and a battery connector to the power wires.
• Controller temperature must never exceed 100C (212F).
• Always verify system current draw at full throttle and confirm servo current draw before the first flight.
• *75 amps is an RC hobby application rating with appropriate cooling.
• **Peak indicates amperage sustainable for 0.5 seconds.
