Castle Creations Phoenix Edge Lite 100 25V 100-Amp ESC w/5-Amp BEC

The Castle Creations Phoenix Edge Lite 100 is a 100-amp brushless ESC for helicopters and fixed-wing aircraft. It supports 2S LiPo to 8S LiPo input voltage, includes a user-selectable 5 to 8.4 volt BEC with 5 amp peak output, and is designed without a heat sink for applications with extreme airflow or average current requirements well below peak current requirements.

Features

• User-programmable auxiliary wire for helicopter governor gain adjustment, audible beacon operation, RPM output, ESC arming lock, or receiver arming lock
• Data logging capability
• Fully programmable Castle feature set using the Castle Link USB adapter and freely downloadable Castle Link Windows software
• Castle Field Link Programming Card compatible with select functions; sold separately
• Intended for helicopters and fixed-wing aircraft

Specifications

• Input voltage: MIN: 2S LiPo; MAX: 8S LiPo
• Max continuous amperage at full throttle: 100 amps*
• BEC voltage: User selectable from 5 to 8.4 volt output
• BEC output amperage: 5 amp peak**
• Width: 1.2" (30.5mm)
• Length: 2.6" (66mm)
• Height: 0.8" (21.4mm)
• Weight w/wires: 3.2 oz (91.5g)
• Weight w/o wires: 1.4 oz (41g)

Installation Notes

• Battery and motor connectors are sold separately.
• A soldering iron and solder are needed to attach bullets to motor wires and the battery connector to the power wires.
• *100 amps is the RC hobby application rating with appropriate cooling. Controller temperature must never exceed 100C (212F). Always verify system current draw at full throttle.
• **Peak indicates amperage sustainable for 0.5 seconds. Confirm servo current draw before the first flight of the model.
