Castle Creations Cobra 10 6S 1/10 Brushless Combo w/1410 Sensored Motor (3800kV)

The Castle Creations Cobra 10 6S 1/10 Brushless Combo pairs a Cobra 10 ESC with a 1410 Sensored Brushless Motor rated at 3800kV. The system features a 32-bit dual-core processor, CRYO-DRIVE™ technology, enhanced data logging, and SmartSense™ and Sensored Only operation modes.

ESC Features

• 32-bit dual-core processor
• Enhanced data logging with faster sampling rates
• CRYO-DRIVE™ technology for reduced operational temperatures
• Water-resistant CNC aluminum case
• 8A peak adjustable BEC
• Premium forged heatsink with elliptical fins
• Thermally controlled 25mm cooling fan
• Auxiliary wire for on-the-fly adjustments
• Audible alerts for diagnostics

Included

• (1) Cobra 10 ESC
• (1) 1410 Sensored Brushless Motor
• (1) Castle Link V4 USB Adapter
• (1) 250mm Direct Connect Sensor Wire
• Product Manual

ESC Specifications

• Suggested Application: 1/10
• Motor Type: Brushless-Sensored
• Input Voltage: 2-6S LiPo (7.4-25.2V)
• Dimensions: 2.2x1.51x1.44in (55.88x38.35x36.58mm)
• Weight: 4.02oz (114g)
• BEC Voltage: 5-8V (5.5V Default)
• BEC Peak Current: 8A
• Motor Connector: 4mm Female Bullets
• Battery Connector: Bare Wire
• Battery Wire: 12AWG
• Programming: Castle Link Windows™ (Windows 10+ Required)

Motor Specifications

• Suggested Application: 1/10
• Size: 3800kV
• Type: Brushless-Sensored
• Voltage: 2-3S LiPo (7.4V-11.1V)
• Connector: 4mm Male Bullets
• Dimensions: 1.68x1.42in (52.7x36mm)
• Shaft Length: 0.59in (15mm)
• Shaft Diameter: 0.12in (3.17mm)
• Weight: 6.8oz (193g)
• Max. Recommended Vehicle Weight: >6.5lbs (104oz)

Tech Notes

• The Cobra 10 ESC is designed to handle up to 6S LiPo batteries, but only allows a maximum of 3S batteries to be used with the included 1410 motor. Check the manual for compatibility and proper input voltage for the wide range of 1410 Motor kV ratings.
• Castle Creations recommends use for 1/10 scale vehicles weighing less than 6.5lbs. Suggested applications are 1/10 scale 2WD and 4WD short course trucks using up to 3S LiPo with conservative gearing, or 1/10 scale buggies and stadium trucks weighing up to 4lbs using a 2-3S LiPo battery.
