Castle Creations 1717 Sensored 4-Pole Brushless Motor (1650Kv)

The Castle Creations 1717 Sensored 4-Pole Brushless Motor delivers 1650Kv output with sensored and sensorless running modes. Its improved 4-pole, 12-slot design is built for efficiency and reduced heat generation in demanding RC applications.

Features

• 1650Kv sensored 4-pole brushless motor
• Sensored and ultra-efficient sensorless running modes
• QUIETSENSE™ technology helps shield sensors from magnetic field noise
• Flux Shield™ and secondary sense magnets support precise, efficient startups
• High-strength, high-temperature grade neodymium sintered magnets with Kevlar rotor wrap
• Oversized NMB bearings and vibration dampening system
• Optimized design eliminates the need for mechanical timing adjustments
• Water resistant design with a silicone conformal-coated sensor board

Specifications

• Input Voltage Range: 8S LiPo
• Max. RPM: 56,000
• Diameter: 1.87” (47.6mm)
• Length: 3.35” (85.1mm)
• Weight (w/wires): 21.08 oz./597.6g
• Shaft Size: 20mm length, 5mm diameter
• Mounting Hole Specifications: M3 and M4 @ 25.4mm (1")
• Cooling Fan: N/A
• Connectors: 6.5mm male bullets
• Recommended ESC: Mamba Monster X 8S
• Recommended Vehicle Weight: Vehicles weighing less than 20lbs.

Application Notes

The 1717-1650Kv is intended for 1/6th scale models weighing up to 20 lbs and running up to 8S LiPo. It can also be used as a high-torque 8S motor upgrade for 1/8th scale models. Monitor motor temperatures closely and never exceed 180° F on the motor or ESC. The sensor connections are not water resistant; apply dielectric grease to the outside of the sensor wire connections after installation and perform routine maintenance after running in wet conditions.
