Castle Creations 1406 Sensored 4-Pole Brushless Motor (6900kV)

The Castle Creations 1406 Sensored 4-Pole Brushless Motor delivers smooth sensored startup, precise low-speed control and efficient sensorless operation through Castle SmartSense™ technology. With a 6900kV rating, it is intended for 1/10th scale on-road cars using 2S LiPo power, as well as lighter off-road 1/10th stadium trucks and buggies with conservative gearing.

Features

• 4-pole, 12-slot design
• SmartSense™ technology combines sensored startup with sensorless running efficiency
• QuietSense™ technology helps keep the motor and ESC in sync
• ROAR standard sensor port with labeled connections
• Rebuildable design with replaceable front end bell, bearings and rotor with shaft
• High-strength 180°C neodymium sintered magnets
• High-quality, temperature-stabilized sensors
• High-purity, high-temperature copper windings
• Hardened stainless steel shaft
• Kevlar wrapped rotor
• 6061-T6 billet aluminum heatsink can
• High RPM NMB oversized bearings
• Oversized gold plated solder tabs
• 4mm male Castle Bullet Connectors

Specifications

• Input Voltage Range: 2 LiPo
• kV: 6900
• Max. RPM: 100,000
• Length: 49.5mm
• Diameter: 36mm
• Weight (w/wires): 193 g / 6.8oz
• Shaft Size: 15mm
• Shaft Diameter: 1/8" (3.17mm)
• Mounting Hole Specifications: M3 @ 25mm
• Cooling Fan: Optional - Coming Soon
• Recommended Vehicle Weight: Up to 4lbs
• Running modes: SMARTSENSE™, Sensored, Sensorless

Application Guidelines

Ideal for 1/10th scale on-road cars for 2s use and lighter off-road 1/10th stadium trucks and buggies with conservative gearing. Not for use in 2WD or 4WD short course trucks. The recommended ESC is the Mamba Max Pro Max.
