Castle Creations 1010 4-Pole 1/14 Sensored Brushless Motor (4400KV)

The Castle Creations 1010 4-Pole 1/14 Sensored Brushless Motor delivers precise throttle control, smooth starts and efficient power for 1/16th and 1/14th scale vehicles weighing up to 3lbs. Its integrated sensor board supports high-precision low-speed control for rock crawling, racing and drag racing applications when paired with a compatible sensored ESC.

Features

• Improved 4-pole, 12-slot design for exceptional efficiency and reduced heat
• QUIETSENSE technology helps shield the sensors from magnetic field noise
• Flux Shield and secondary Sense Magnets support precise, efficient startups
• Optimized design eliminates the need for mechanical timing adjustments
• Sensor alignment provides uniform timing and torque in both directions
• SmartSense, Sensored and ultra-efficient Sensorless running modes
• Oversized NMB bearings and vibration dampening system
• High-strength, high-temperature grade neodymium sintered magnets with a high-strength Kevlar wrap

Specifications

• Input Voltage Range: 2s - 4s LiPo
• Kv: 4400
• Max. RPM: 80,000
• Length: 58.4mm
• Diameter: 28mm
• Weight (w/wires): 5.17oz (146.5g)
• Shaft Length: 15mm
• Shaft Diameter: 1/8" (3.175mm)
• Mounting Hole Specifications: 2.5mm @ 14mm & 16mm; 3mm @ 19mm
• Connectors: 4mm male Castle Bullet Connectors attached to replaceable 16 gauge wire
• Sensored Wire: 210mm length

Application

• Ideal for 1/16th and 1/14th scale vehicles weighing up to 3lbs
• Recommended ESC: Mamba Micro X2
• Compatible Electronic Speed Control (ESC) required for operation

Includes

• (1) 1010 4-Pole 1/14 Sensored Brushless Motor (4400KV)
• (1) Sensor Cable (210mm)
